Vermeer Machine Part Number Mfr. Method Mid-Body Tool Joint OD Length Weight (lbs.) Connection Max Torque % Slope Per Rod Bend Radius Rack Quanitity
D7X11, D9X13, D10x15 TR216492 1-pc. Forged 1.660″ 1.875″ 6′ 26 Firestick™ 1 #200 1,500 6.2% 97′ 33/50
D16X20, D18X22, D20x22 TR230993 1-pc. Forged 1.900″ 2.125″ 10′ 53 Firestick™ 1 #250 2,000 10.2% 98′ 40
D20X22, D24X26, D23x30 TR221628 1-pc. Forged 2.063″ 2.250″ 10′ 60 Firestick™ 1 #400 2,600 9.8% 102′ 40
D24X40, D23x30 TR222276 1-pc. Forged 2.375″ 2.625″ 10′ 77 Firestick™ 1 #600 4,000 9.3% 108′ 50
D36X50, D40x55  (#650 x 10′) TR296309599 1-pc. Forged 2.375″ 2.750″ 10′ 83 Firestick™ 1 #650 5,000 9.3% 108′ 50/52
D36X50  (#650 x 15′) TR296312531 1-pc. Forged 2.375″ 2.750″ 15′ 117 Firestick™ 1 #650 5,000 13.9% 108′ 40
D36X50, D40x55  (#700×10′) TR296309521 1-pc. Forged 2.625″ 3.100″ 10′ 121 Firestick™ 1 #700 5,000 6.9% 145′ 45
D36X50, D40x55  (#700×15′) TR296309522 1-pc. Forged 2.625″ 3.100″ 15′ 171 Firestick™ 1 #700 5,000 10.4% 145′ 35
D50x100,  D60x90 TR222452 1-pc. Forged 2.875″ 3.250″ 15′ 172 Firestick™ 1 #900 9,000 8.7% 169′ 40
D80X100, D50x100,  D60x90 TR222454 1-pc. Forged 3.500″ 3.625″ 15′ 220 Firestick™ 1 #800 10,000 7.5% 200′ 12/24
D100X120, D100x140 TR296309520 1-pc. Forged 3.500″ 4.375″ 20′ 342 Firestick™ 1 #1000 15,000 10.2% 200′ 9/18
Ditch Witch® Machine Part Number Mfr. Method Mid-Body Tool Joint OD Length Weight (lbs.) Connection Max Torque % Slope Per Rod Bend Radius Rack Quanitity
JT520 Power Pipe ® HD (fine thread) TR355-1052 Inertia Welded 1.125″ 1.750″ 4.9′ 16 DW 1.21-6 500 7% 70′ 30
JT520 Power Pipe ®  (coarse thread) TR355-1066 Inertia Welded 1.125″ 1.875″ 4.9′ 16 DW 1.10-5 500 7% 70′ 30
JT5 Power Pipe ® HD (coarse thread) TR355-1038 Inertia Welded 1.125″ 1.875″ 4.9′ 17 DW 1.10-5 550 7% 70′ 30
JT820/JT920/JT921 TR400-963 1-pc. Forged 1.580″ 2.000″ 6.5′ 28 DW 1.41-6 1,100 6.5% 100′ 56
JT920L TR400-842 1-pc. Forged 1.625″ 2.000″ 10′ 37 DW 1.41-6 1,100 9.7% 100′ 40
JT9 / JT922/ JT10 Power Pipe ® HD (coarse) TR355-1149 or TR355-1034 1-pc. Forged 1.580″ 2.000″ 6′ 26 DW 1.30-5 1,100 6.0% 100′ 50
JT1220 Power Pipe ® TR355-1005 1-pc. Forged 1.820″ 2.375″ 10′ 52 DW 1.47-4 1,400 8.3% 120′ 40
JT1720/1720M1 TR400-843 1-pc. Forged 2.125″ 2.500″ 10′ 60 DW 1.69-6 1,800 8.8% 115′ 44
JT20 / JT2020 Power Pipe ® HD TR401-339 or   TR355-1106 1-pc. Forged 2.125″ 2.625″ 10′ 69 DW 1.94-4 2,200 8.8% 115′ 40
JT25 / JT30 / JT2720M1 Power Pipe ® HD TR355-1094 1-pc. Forged 2.375″ 2.750″ 9.8′ 77 DW 2.11-4 4,000 8.0% 123′ 25/50
JT2720 Power Pipe ® TR400-844 1-pc. Forged 2.375″ 2.750″ 9.8′ 77 DW 1.94-4 3,200 6.9% 145′ 25/50
JT2720M1 / 3020M1 TR400-1031 1-pc. Forged 2.375″ 3.000″ 9.8′ 90 DW 2.11-4 4,000 6.5% 150′ 24/48
JT4020 Power Pipe ® TR400-846 1-pc. Forged 2.875″ 3.250″ 14.75′ 165 DW 2.40-4 5,000 8.0% 185′ 16/32
JT4020M1 Power Pipe ® TR400-847 1-pc. Forged 2.875″ 3.500″ 14.75′ 176 DW 2.59-4 5,000 8.0% 185′ 16/32
JT40 Power Pipe ® HD TR355-1210 1-pc. Forged 2.810″ 3.125″ 15′ 150 DW 2.10-4 5,500 10.2% 146′ 20/40
JT60 Power Pipe ® HD TR355-1079 1-pc. Forged 3.0625″ 3.500″ 15′ 184 DW 2.46-4 9,000 8.8% 170′ 16/28
JT7020/8020/JT100 Power Pipe ® HD TR368-665 or TR355-1200 1-pc. Forged 3.500″ 4.000″ 14.75′ 225 DW 3.27-4 10,000 7.2% 205′ 12
